Single phase 660VAC 50Kvar 365uf 50Hz
Technical data
Rated voltage: 660VAC
Rated capacity: 50 Kvar
Rated current: 75.8A
Rated capacitance: 365μF -3%～+5%
Rated frequency: 50Hz
Internal structure: 37 paralles 1 series
Protection: Internal fuses and discharge resistor
Solid medium: Polypropylene film
Liquid medium: Low temperature impregnating agent （Non-PCB）
Insulation level: AC 5 kV(60s)/LI 25 kV(1.2/50μs)
Creepage: ≥50 mm
Weight: 41kgs ±2
Working Environment: Indoor
Altitude: max 2000m
Overcurrent: 1.3 In
Overvoltage: 1.1Un (12 hours every 24 hours)
Dielectric Loss: ≤0.3W/kvar
Shell Material: cold-rolled sheet
Shell Explosion Resistance: 15KJ
Cooling Method: natural cool
Complied Standards: GB/T11024.1-2019/IEC60871-1:2014
