Film capacitor for low-flying aircraft
As is known to all, Electric vehicles/automobiles is internationally popular and promotion of green transport, with its pollution, no noise, low-power, low road occupation, convenient and aroused great attention. The unmanned aerial vehicle technology is way more than mature. Will the low-altitude aircraft be the next popular means of transportation? It seems the pattern of the development.
Due to operating conditions, airborne components must comply with strict reliability and safety requirements. The atmospheric conditions like the air density, cooling properties of air, dielectric strength of air must be considered for low-altitude E-aircrafts.
The development of busbar film capacitors specifically designed for aircraft applications represents a significant advancement in the field of e-aviation. These electronic components are engineered to meet the unique demands of low-altitude flight, ensuring optimal performance and reliability. The integration of such advanced electronics solutions is pivotal for the evolution of electric aircraft, enabling them to operate efficiently and safely in the air.
The busbar film capacitor can meet the life requirements of aircraft operation for 3000h, and the capacitor limit test condition runs continuously for 4000h under the working condition of high temperature 115℃ and high voltage 400Vdc. The capacitor still maintains excellent electrical performance and function, and the capacity attenuation is less than -3%.
Rated power: 20kW～160kW
Switch frequency: 10Khz
Working enviroment: 110℃
Technical Parameter:
Capacitance: 100~1000uF
Rated Volatge: 400~1000V
Rated ripple current: 50~70A
Stray inductance：≦10nH
Working environment: -45～115℃
Features
Excellent resistance to active and passive flammability
Over-voltage capability
Low losses with high current capability
High reliability
High temperature resistance
● Rated Power: 20kW~160kW driving power
● Capacitance: 100~1000uF
● Rated Voltage: 400~1000V
● Rated Ripple current: 80A
● Stray inductance:≦ 10nH
● Working environment:-45～115℃
