2000Kvar water cooled capacitor
01
1200VAC 2000Kvar 442.1uf 500hz water cooled capacitor
Power capacitor specially designed for Induction heating & melting application;
Product Standard：GB/T3984.1(Equivalent to IEC60110.1)
|
Particulars |
Rated Value |
|
UN(kv) |
1.2(AC) |
|
QN(kvar) |
2000 |
|
CN(μF) |
442.1 |
|
fN(kHz) |
0.5 |
|
IN(A) |
1667 |
|
Shell Case |
Non-insulated |
|
Nos.of Cooling Water Tube |
1 |
|
Water flow |
≥8L/min |
|
Water temperature |
≤35℃ |
|
Capacitance Tolerance |
-200 |
|
TERM |
μF |
|
C-1 |
55.3 |
|
C-2 |
55.3 |
|
C-3 |
55.3 |
|
C-4 |
55.3 |
|
C-5 |
55.3 |
|
C-6 |
55.3 |
|
C-7 |
55.3 |
|
C-8 |
55.3 |
|
Material of Tank |
Aluminium Alloy Plate |
|
Terminal Conduit |
Insulator(White) |
|
Max. Tightening Torque |
18N·m |
|
Insulation Oil |
PEPE(non-PCB) |
|
Dimension Tolerance of Terminals |
±3% |
|
Dimension Tolerance of Brackets |
±3% |
|
Dimension Tolerance of Oil Tank |
±3% |
