750VAC 1000Kvar 6Khz induction Furnace capacitor

Particulars

Rated Value

UN(kv)

0.75(AC)

QN(kvar)

1000

CN(μF)

47.2

fN(kHz)

6

IN(A)

1333

Shell Case

Insulated

Nos.of Cooling Water Tube

1

Water flow

≥6L/min

Watertemperature

≤35℃

TERM

μF

C-1

7.87

C-2

7.87

C-3

7.87

C-4

7.87

C-5

7.87

C-6

7.87

Dimension Tolerance of Terminals

±2%

Dimension Tolerance of Brackets

±2

Dimension Tolerance of case

±2

Material of Tank

Metal

Terminal electrode

Compound Material insulator

Max. Tightening Torque

16N·m

Insulation Oil

PEPE(non-PCB)
