High-capacity DC support capacitor

Description
The windpower, solar power, HVDC is developing fast. So the power system faces the demand of diversity regulation. Required by time and tide, a great attention is devoted to power conversion, energy storage and transmission. Flair has been offering capacitors for power conversion, energy storage and power distribution and transmission. With our rich experience and strong RD team, we focus on providing with the most professional propoals and serving high-quality products failthfully and responsibly.

High voltage and high current working enviroment will accelerate the aging of capacitors that cause capacitor faulture easily. We studied on this project since 2017 when the national double carbon call is promoted. We have conquered key technology of large-capacity DC capacitor banks with satisfactory operation under harsh working enviroment.

product details

DC support capacitor benefits

♢ High-voltage withstand ability: DC support capacitor is capable of supporting higher voltage more than normal capacitors. So it is suitable for dc power filter and high voltage dc transmission.

♢ Low loss: Its low loss feature make it is resultful to work as store and release electrical energy, as well as increase efficient and performance of the system.

♢ Long-lifespan: By applying for high-quality insulation material and stable dielectric, we make it’s reliable capacitance value and low ESR.

♢ Good frequency response: Even in high frequency ranged dc support capacitor performed good, keep its capacitance value stable and low ESR, such as power electronics, communication devices etc.

DC support capacitor Features

♢ Dielectric: Self-healing metalized film

♢ Expoxy perfusion

♢ Hermetically sealed for prevent capacitor from mositure

♢ Custom-design available

♢ High voltage range of 1KV-100KV with standard and custom design options

DC voltage filtering capacitor application

♢ DC link filtering/support

♢ Resonant filtering

♢ Active correction ( Power factor correction)

♢ HVDC

♢ High Power DC Supply

♢ Speed converter (drives and traction)

♢ Windmills

♢ Substation

♢ Solar power

Reference delivered capacitors

No	Project	Capacitors specification	capacitor type
1	Offshore wind power transmission	9000uf 2800VDC	Dry type metalized film capacitor
2	Power Distribution network	8000uf 2800VDC
3	Low frequency transmission	7000uf 2800VDC
4	Power distribution network	10000uf 2200VDC
5	SVG	4000uf 2800VDC
6	SVG	12000uf 2300VDC
7	SVG	10000uf 2300VDC
8	Frequency conversion	2000uf 6000VDC
9	SVG	20000uf 2100uf
10	N	4000uf 4000VDC
11	N	100uf 7500VDC
12	N	2200uf 12000VDC
13	N	11000uf 2200VDC
14	N	7500uf 2800VDC
15	N	6000uf 2800VDC
